SPECIFICATIONS
General description
2-way ‘on wall’ loudspeaker
Enclosure type
closed-box
Transducer complement
2-way
Bass driver
6.5″ ( 150mm) advanced PP Cone x2
Treble driver
1″ (25mm) Textile Dome
Sensitivity (2.83V@ 1m)
88dB
Recommended amplifier power
40-150W
Peak power handling
150W
Peak SPL
102dB
Nominal impedance
4Ω Compatible
Minimum impedance
4.3Ω
Frequency response (+/-3dB)
90Hz~20kHz
Bass extension (-6dB)
85Hz
Crossover frequency
2.8kHz
Dimensions (mm)
Height
560mm
Width
200mm
Depth (with grille+bracket)
141mm
