QX-2 MKII Specifications
QX-2 MKII Specifications
| General Description | 2-way Bookshelf Speaker |
| Enclosure Type | Bass Reflex |
| Transducer Complement | 2-way |
| Bass Driver | 6.5″(165mm) Long Fiber Composite Cone |
| Treble Driver | 1.5″(38mm) Textile Ring Dome |
| AV Shield | No |
| Sensitivity (2.0V @ 1m) | 88dB |
| Recommended Amplifier Power | 25-120W |
| Peak SPL | 95dB |
| Nominal Impedance | 4 Ω (compatible 8Ω) |
| Minimum Impedance | 3.6Ω |
| Frequency Response (+/-3dB) | 44Hz ~ 24kHz |
| Bass Extension (-6dB) | 38Hz |
| Crossover Frequency | 2.2kHz |
| Cabinet Volume (in litres) | 13.5L |
| Height (on plinth) | 320mm |
| Width | 220mm |
| Depth (with terminals) | (300+10)mm |
| Carton Size | 570 x 395 x 420mm |
| Net Weight | 8.5kg/pcs |
| Gross Weight | 19.0kg/ctn |
