QX-3 MKII Specifications
QX-3 MKII Specifications
| General Description | 2-way Floorstanding Speaker |
| Enclosure Type | Bass Reflex |
| Transducer Complement | 2-way |
| Bass Driver | 5″ (135mm) Long Fiber Composite Cone x2 |
| Treble Driver | 1.5″(38mm) Textile Ring Dome |
| AV Shield | No |
| Sensitivity (2.0V @ 1m) | 88dB |
| Recommended Amplifier Power | 25-120W |
| Peak SPL | 95dB |
| Nominal Impedance | 4 Ω (compatible 8Ω) |
| Minimum Impedance | 3.8Ω |
| Frequency Response (+/-3dB) | 42Hz ~ 24kHz |
| Bass Extension (-6dB) | 36Hz |
| Crossover Frequency | 2.0kHzz |
| Cabinet Volume (in litres) | 35L |
| Height (on plinth) | (950+20)mm |
| Width | 195mm |
| Depth (with terminals) | (300+10)mm |
| Carton Size | 435 x 325 x 1100mm |
| Net Weight | 20.0kg/pcs |
| Gross Weight | 23kg/ctn |
