QX-5 MKII Specifications
QX-5 MKII Specifications
| General Description | 3-way Floorstanding Speaker |
| Enclosure Type | Bass Reflex |
| Transducer Complement | 3-way |
| Bass Driver | 12″ (300mm) Cone Long-throw x1 |
| Midrange Driver | 6.5″ (165mm) Long Fiber Composite Cone x2 |
| Treble Driver | 1.5″(38mm) Textile Ring Dome |
| AV Shield | No |
| Sensitivity (2.0V @ 1m) | 90dB |
| Recommended Amplifier Power | 30-200W |
| Peak SPL | 96dB |
| Nominal Impedance | 4 Ω (compatible 8Ω) |
| Minimum Impedance | 3.5Ω |
| Frequency Response (+/-3dB) | 32Hz ~ 24kHz |
| Bass Extension (-6dB) | 27Hz |
| Crossover Frequency | 180Hz,1.8kHz |
| Cabinet Volume (in litres) | 16L/48L |
| Height (on plinth) | (1100+20)mm |
| Width | 220mm |
| Depth (with terminals) | (400+10)mm |
| Carton Size | 535 x 350 x 1250mm |
| Net Weight | 34kg/pcs |
| Gross Weight | 38.0kg/ctn |
