ZX-4 Specifications
ZX-4 Specifications
| General Description | 3-way floorstanding speaker |
| Enclosure Type | Bass reflex |
| Transducer Complement | 3-way |
| Bass Driver | 5.25″ (130mm) aluminium cone x2 |
| Midrange Driver | 5.25″ (130mm) aluminium cone |
| Treble Driver | 1.5″ (38mm) ring dome |
| AV Shield | No |
| Sensitivity (2.0V @ 1m) | 90dB |
| Recommended Amplifier Power | 25-150W |
| Peak SPL | 110dB |
| Nominal Impedance | 4 Ohms(compatible 8 Ohms) |
| Minimum Impedance | 3.4 Ohms |
| Frequency Response(+/-3dB) | 40Hz ~ 24kHz |
| Bass Extension(-6dB) | 35Hz |
| Crossover Frequency | 530Hz,2.7kHz |
| Dimensions (HxWxD) | 1075 x 240 x (350+12)mm |
| Net Weight | 24.6kg/pcs |
